Modern Ejector technology offers you flexibility and a new safe way of working. The Modern Ejector Bin is suitable for spreading or bulk tipping & eliminates the risk of tipping rollovers. It also allows you to easily eject with overhead obstructions and spread on side angles or even while driving downhill.
5 models are available in this range
3 Axle Modern Semi Ejector Trailer
Modern Ejector technology offers you innovation, flexibility and a new safe way of working. The Modern Ejector Bin is suitable for spreading or bulk tipping and has added compatibility with standard paving machines & eliminates the risk of tipping rollovers. It also allows you to easily eject with overhead obstructions and spread on side angles or even while driving downhill. Electronic alarms for operator assistance add to the complete package.
An innovation in the traditional tipper market.
| STANDARD SPECIFICATIONS | |
| GVM | 33,000kg |
| Tare | From 8,400kg |
| Bin Sides Thickness | 4mm Hardox |
| Bin Floor Thickness | 5mm Hardox |
| Bin Rear Thickness | 4mm Hardox |
| Bin Front Thickness | 4mm Hardox |
| Side Height | 1000mm |
| Bin Length Overall | 9400mm |
| Bin Length Inside | 8700mm |
| Bin Width Overall | 2490mm |
| Bin Width Inside | 2340mm |
| Capacity | 20m3 |
| Ejecting Cylinders | 5 Double-acting |
| Tailgate | Two-way demo door |
| Axles | 19.5” MTW |
| Suspension | Air |
| Brakes | Knorr-Bremse ABS Disc |
| Hydraulic Supply | Truck |
| King Pin | 50mm |
| Landing Legs | Jost full weight |
| Tarp | Power Tarps electric retractable |
| Wheels | Weight Cheetah 19.5” |
| Tyres | 265/70R |
4 Axle Modern Semi Ejector Trailer
Modern Ejector technology offers you innovation, flexibility and a new safe way of working. The Modern Ejector Bin is suitable for spreading or bulk tipping and has added compatibility with standard paving machines & eliminates the risk of tipping rollovers. It also allows you to easily eject with overhead obstructions and spread on side angles or even while driving downhill. Electronic alarms for operator assistance add to the complete package.
An innovation in the traditional tipper market.
| STANDARD SPECIFICATIONS | |
| GVM | 29,000kg |
| Tare | 7440kg |
| Bin Sides Thickness | 4mm Hardox |
| Bin Floor Thickness | 5mm Hardox |
| Bin Rear Thickness | 4mm Hardox |
| Bin Front Thickness | 4mm Hardox |
| Side Height | 1000mm |
| Bin Length Overall | 6900mm |
| Bin Length Inside | 6100mm |
| Bin Width Overall | 2490mm |
| Bin Width Inside | 2340mm |
| Capacity | 14m3 |
| Ejecting Cylinders | 5 Double acting |
| Tailgate | Two-way demo door |
| Axles | 19.5” MTW |
| Suspension | MTW Air |
| Brakes | Knorr-Bremse ABS Disc |
| Hydraulic Supply | Truck |
| Tow Eye | 50mm |
| Tarp | Power Tarps electric retractable |
| Wheels | Weight Cheetah 19.5” |
| Tyres | 265/70R |
5 Axle Modern Semi Ejector Trailer
Modern Ejector technology offers you innovation, flexibility and a new safe way of working. The Modern Ejector Bin is suitable for spreading or bulk tipping and has added compatibility with standard paving machines & eliminates the risk of tipping rollovers. It also allows you to easily eject with overhead obstructions and spread on side angles or even while driving downhill. Electronic alarms for operator assistance add to the complete package.
An innovation in the traditional tipper market.
| STANDARD SPECIFICATIONS | |
| GVM | 32,000kg |
| Tare | 9800kg |
| Bin Sides Thickness | 4mm Hardox |
| Bin Floor Thickness | 5mm Hardox |
| Bin Rear Thickness | 4mm Hardox |
| Bin Front Thickness | 4mm Hardox |
| Side Height | 1000mm |
| Bin Length Overall | 9400mm |
| Bin Length Inside | 8700mm |
| Bin Width Overall | 4290mm |
| Bin Width Inside | 2340mm |
| Capacity | 20m3 |
| Ejecting Cylinders | 5 Double acting |
| Tailgate | Two-way demo door |
| Axles | 19.5” MTW |
| Suspension | MTW Air |
| Brakes | Knorr-Bremse ABS Disc |
| Hydraulic Supply | Truck |
| Tow Eye | 50mm |
| Tarp | Power Tarps electric retractable |
| Wheels | Weight Cheetah 19.5” |
| Tyres | 265/70R |
SINOTRUK C7H 6X4 EJECTOR
Modern Ejector technology offers you innovation, flexibility and a new safe way of working. The Modern Ejector Bin is suitable for spreading or bulk tipping and has added compatibility with standard paving machines & eliminates the risk of tipping rollovers. It also allows you to easily eject with overhead obstructions and spread on side angles or even while driving downhill. Electronic alarms for operator assistance add to the complete package.
An innovation in the traditional tipper market.
| STANDARD SPECIFICATIONS | |
| GVM | 25,000kg |
| Tare | 12,000kg |
| GCM | 75,000kg |
| Engine | MC13.54-50 |
| Displacement | 12.419L |
| Power rating | 397/1900 kW/(r/min) |
| Max torque | 2500/1050-1350 Nm/(r/min) |
| Transmission | HW25712XS(Manual) with PTO |
| Suspension | Spring |
| Body Length | 4700mm |
| Body Width Overall | 2490mm |
| Side Height | 1000mm |
| Capacity | 11m3 |
| Body Material | Hardox Steel |
| Tailgate | Demo Door |
SINOTRUK C7H 8X4 EJECTOR
Modern Ejector technology offers you innovation, flexibility and a new safe way of working. The Modern Ejector Bin is suitable for spreading or bulk tipping and has added compatibility with standard paving machines & eliminates the risk of tipping rollovers. It also allows you to easily eject with overhead obstructions and spread on side angles or even while driving downhill. Electronic alarms for operator assistance add to the complete package.
An innovation in the traditional tipper market.
| STANDARD SPECIFICATIONS | |
| GVM | 32,000kg |
| GCM | 75,000kg |
| Engine | MC13.54-50 |
| Displacement | 12.419L |
| Power rating | 397/1900 kW/(r/min) |
| Max torque | 2500/1050-1350 Nm/(r/min) |
| Transmission | HW25712XS(Manual) with PTO |
| Suspension | Spring |
| Body Length | 6100mm |
| Body Width Overall | 2490mm |
| Side Height | 1000mm |
| Capacity | 14m3 |
| Body Material | Hardox Steel |
| Tailgate | Demo Door |
